VXF-8
UIELOCK
The VXF-8 is a high-performance smart door lock designed for modern homes and businesses, combining multiple access methods with robust security features. It supports fingerprint recognition, NFC M1 card, 6-12 digit passwords, mechanical key backup, and remote Wi-Fi management via a companion app. The lock features a durable stainless steel construction, is suitable for both indoor and outdoor use, and operates on four AA batteries with an emergency USB power option. With a capacity for up to 200 users, including administrators and ordinary users, it offers flexible and scalable access control.
The system includes a backlit keypad, audible feedback, and an optional doorbell function. Its intuitive menu allows users to easily configure settings such as language, volume, auto-lock time, and anti-theft alarms. Built-in logs track all access events, providing transparency and security oversight.
Product Parameters
Material: Stainless Steel
Size: 375mm*159mm*73.5mm
Unlock Method: Fingerprint+Password+Card+Key+APP
Remote unlocking:Yes
Response Time: ≦0.5S
Operating temperature:-25℃~70℃
Core grade:Level C
Emergency Power Supply: Type-C(5V)
Power Supply: Rated voltage DC 6V (AA/AAA, dry battery)
Lock Body: International Mechanical Lock Body
Door Thickness: 40-120mm
Capacity: 100 groups Fingerprint + 100 groups password + 100 groups card
Product characteristics
**Semiconductor fingerprint technology, speed unlock
**One-time temporary key, remote unlock
**High appearance level design, suitable for 95% of the market door types
**Aviation aluminum/Excellent corrosion resistance and durability
**Support Tuya networking
The VXF-8 is a high-performance smart door lock designed for modern homes and businesses, combining multiple access methods with robust security features. It supports fingerprint recognition, NFC M1 card, 6-12 digit passwords, mechanical key backup, and remote Wi-Fi management via a companion app. The lock features a durable stainless steel construction, is suitable for both indoor and outdoor use, and operates on four AA batteries with an emergency USB power option. With a capacity for up to 200 users, including administrators and ordinary users, it offers flexible and scalable access control.
The system includes a backlit keypad, audible feedback, and an optional doorbell function. Its intuitive menu allows users to easily configure settings such as language, volume, auto-lock time, and anti-theft alarms. Built-in logs track all access events, providing transparency and security oversight.
Product Parameters
Material: Stainless Steel
Size: 375mm*159mm*73.5mm
Unlock Method: Fingerprint+Password+Card+Key+APP
Remote unlocking:Yes
Response Time: ≦0.5S
Operating temperature:-25℃~70℃
Core grade:Level C
Emergency Power Supply: Type-C(5V)
Power Supply: Rated voltage DC 6V (AA/AAA, dry battery)
Lock Body: International Mechanical Lock Body
Door Thickness: 40-120mm
Capacity: 100 groups Fingerprint + 100 groups password + 100 groups card
Product characteristics
**Semiconductor fingerprint technology, speed unlock
**One-time temporary key, remote unlock
**High appearance level design, suitable for 95% of the market door types
**Aviation aluminum/Excellent corrosion resistance and durability
**Support Tuya networking
Multi-Mode Access: Unlock via fingerprint, password, M1 card, key, or remotely via Wi-Fi.
High Security: Features anti-peeping password protection, false attempt lockout (90 seconds after 5 wrong tries), and encryption support for cards and fingerprints.
Large User Capacity: Supports up to 200 users—ideal for families, offices, or rental properties.
Durable & Weather-Resistant: Works in temperatures from -25°C to 70°C, with sunproof and waterproof design.
Easy Installation & Use: Clear visual and voice prompts in multiple languages; simple DIY installation with included hardware.
Smart Alerts: Low battery warning, anti-tamper alarm, and real-time access logs.
Emergency Ready: USB power backup and mechanical key override ensure access during power loss.
Remote Management: Add or remove users, check logs, and control settings via app when connected to Wi-Fi
Multi-Mode Access: Unlock via fingerprint, password, M1 card, key, or remotely via Wi-Fi.
High Security: Features anti-peeping password protection, false attempt lockout (90 seconds after 5 wrong tries), and encryption support for cards and fingerprints.
Large User Capacity: Supports up to 200 users—ideal for families, offices, or rental properties.
Durable & Weather-Resistant: Works in temperatures from -25°C to 70°C, with sunproof and waterproof design.
Easy Installation & Use: Clear visual and voice prompts in multiple languages; simple DIY installation with included hardware.
Smart Alerts: Low battery warning, anti-tamper alarm, and real-time access logs.
Emergency Ready: USB power backup and mechanical key override ensure access during power loss.
Remote Management: Add or remove users, check logs, and control settings via app when connected to Wi-Fi
Homeowners seeking keyless, high-security entry with family and guest access management.
Landlords & Property Managers needing temporary access codes or remote user management.
Small & Medium Businesses requiring reliable access control for offices, storage rooms, or shared spaces.
Airbnb & Vacation Rental Hosts who want to automate guest check-in/out without physical key exchange.
Individuals desiring modern convenience combined with traditional key backup.
Homeowners seeking keyless, high-security entry with family and guest access management.
Landlords & Property Managers needing temporary access codes or remote user management.
Small & Medium Businesses requiring reliable access control for offices, storage rooms, or shared spaces.
Airbnb & Vacation Rental Hosts who want to automate guest check-in/out without physical key exchange.
Individuals desiring modern convenience combined with traditional key backup.
Q: How many users can the lock store?
A: Up to 200 total users across fingerprints, passwords, and M1 cards. This includes up to 10 administrator accounts.
Q: What happens if the battery runs out?
A: The lock will give a voice warning when voltage is low. You can use a 5V power bank via the USB port on the front panel or the mechanical key to unlock.
Q: Can I use it without Wi-Fi?
A: Yes. Wi-Fi is optional for remote features. All local functions—fingerprint, card, password, and key—work without an internet connection.
Q: Is the fingerprint sensor accurate in wet or cold conditions?
A: Yes, it has a high recognition rate (FAR < 0.001%) and operates in temperatures from -25°C to 70°C.
Q: Can I set a temporary password for guests?
A: Yes, through the app (Wi-Fi mode) or directly on the keypad via administrator settings.
Q: What type of batteries does it use?
A: Four AA alkaline batteries (recommended). Battery life depends on usage but typically lasts 12–18 months.
Q: Is installation difficult?
A: No. The package includes a detailed manual, installation template, and all necessary screws and rods. Standard door thickness of 35–55 mm is supported.
Q: How do I reset the lock if I forget the administrator password?
A: Use the mechanical key to enter, then reset the system via the initialization command (see manual). Note: This will erase all user data.
Q: How many users can the lock store?
A: Up to 200 total users across fingerprints, passwords, and M1 cards. This includes up to 10 administrator accounts.
Q: What happens if the battery runs out?
A: The lock will give a voice warning when voltage is low. You can use a 5V power bank via the USB port on the front panel or the mechanical key to unlock.
Q: Can I use it without Wi-Fi?
A: Yes. Wi-Fi is optional for remote features. All local functions—fingerprint, card, password, and key—work without an internet connection.
Q: Is the fingerprint sensor accurate in wet or cold conditions?
A: Yes, it has a high recognition rate (FAR < 0.001%) and operates in temperatures from -25°C to 70°C.
Q: Can I set a temporary password for guests?
A: Yes, through the app (Wi-Fi mode) or directly on the keypad via administrator settings.
Q: What type of batteries does it use?
A: Four AA alkaline batteries (recommended). Battery life depends on usage but typically lasts 12–18 months.
Q: Is installation difficult?
A: No. The package includes a detailed manual, installation template, and all necessary screws and rods. Standard door thickness of 35–55 mm is supported.
Q: How do I reset the lock if I forget the administrator password?
A: Use the mechanical key to enter, then reset the system via the initialization command (see manual). Note: This will erase all user data.
